for Latch Type Toggle Clamps GN 852 / GN 852.3
GN 951.2 Stainless Steel Square U-Bolts
| d1 | b | l1 | d2 | l3 | Size | GN 852 / GN 852.3 r at w2=0 | w2 | Size | GN 852.1 r at w2=0 | w2 |
|---|---|---|---|---|---|---|---|---|---|---|
| M 10 | 46 | 129* | 9 | 45 | 1700 | 96 | 15 | 1400 | 95 | 15 |
| M 10 | 46 | 179 | 9 | 45 | 1700 | 146 | 15 | 1400 | 145 | 15 |
| M 10 | 46 | 209 | 9 | 45 | 1700 | 176 | 15 | 1400 | 175 | 15 |
| M 10 | 46 | 259 | 9 | 45 | 1700 | 226 | 15 | 1400 | 225 | 15 |
| M 12 | 55 | 151* | 10,8 | 70 | 4000 | 107 | 25 | - | - | - |
| M 12 | 55 | 211 | 10,8 | 70 | 4000 | 156 | 36 | - | - | - |
| M 12 | 55 | 361 | 10,8 | 70 | 4000 | 306 | 36 | - | - | - |
| M 12 | 55 | 421 | 10,8 | 70 | 4000 | 366 | 36 | - | - | - |
Filter combination produces no result.
* These square U-bolt lengths are included in the delivery of standard orders for GN 852 / GN 852.3.
Specification
Stainless steelNI AISI 304
Hexagon nuts
(with polyamide insert)
DIN 936 / DIN 985
Stainless steel
RoHS
Hexagon nuts
(with polyamide insert)
DIN 936 / DIN 985
Stainless steel
RoHS
Information
| How to order |
| ||||||||
GN 951.2-M10-46-259-NI |
