Aluminum
GN 272.4 Sensor Holders
| d1 Bore for sensor | b Swivel width | d2 | d3 | Length l | m1 | m2 | t1 | t2 | x1 | x2 | y1 | y2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| B 18 | 40 | 50 | 6,5 | 52,5 | 32,5 | 30 | 10 | 7 | 60 | 42 | 60 | 42 |
| B 30 | 40 | 50 | 6,5 | 52,5 | 32,5 | 30 | 10 | 7 | 60 | 42 | 60 | 42 |
Filter combination produces no result.
Specification
Aluminum
Powder coated
Black, RAL 9005, textured finishSW
RoHS
Powder coated
Black, RAL 9005, textured finishSW
RoHS
On request
Stainless steel version
Information
Sensor holders GN 272.4 accept sensors with external thread via the hole in the lug.
| How to order |
| ||||||
GN 272.4-B30-40-SW |
